Transmission Deep/Cooling Pan E40D/4R100/5R100 Derale

Description

Transmission Cooling Pan redirects the air passing beneath the vehicle to help lower transmission oil temperatures. Designed for Ford Trucks with E40D, 4R100,5R100 Heavy-duty transmissions, this pan features brazed, turbulator-equipped airway tubes. Tubes pass through the lower section of the transmission pan for more efficient cooling. In addition, each pan is individually pressure tested to ensure it is leak-free. A powerful magnetic drain plug and rubbers/steel reusable washers are included, as well as 1/8″ NPT temperature sender bung located in the side of the pan. Finished with durable black two-stage coating, each pan also includes a neoprene gasket and 1/8″ NPT temperature sender plug.

FEATURES:

• 1/8″ NPT Temperature Sender Port
• Heavy Gauge Stamped Steel Construction
• Two Stage Heat Dissipating Black Finish
• Reduces Fluid Temperature Up to 10C
• Increases Fluid capacity by 6.6L
• Uses OEM Filter With no Filter Extension  Required
• Patented Turbulator Cooling Tubes Add Heat Transfer Capability
• Magnetic Drain Plug With Increased Magnetic Strength and Rubber/Steel washer

Specifications

• Pan Dimensions: 518 mm (L) × 349 mm (W) × 161 mm (H)
• Drain Plug Height Addition: 6 mm
• Tube Depth: 108 mm
• Temp Bung Size: 1/8″ NPT
• Drain Plug Size: 1/2″-20 UNF
